Features of Sonnet batteries
|
 |
1st and 2nd Generation iPods
1st Generation iPod features a scroll wheel that turns. The Play, Menu, Next, and Previous buttons are located around the scroll wheel. A FireWire port is located on the top of the iPod. 2nd Generation iPod is similar to the 1st Generation model but features a touch wheel that does not physically turn.
|
|
|
BAT-1G2G
|
Part No.
|
BAT-1G2G |
| Capacity: |
2200 mAh |
| Replaces: |
iPod battery model
UP325385A4H, UP325385A5H |
Package Includes:
High-capacity iPod battery, two non-scratching nylon case opening tools, and a CD-ROM with QuickTime installation videos. |
|
 |
3rd Generation iPod
3rd Generation iPod features a touch wheel with four separate buttons (Play, Menu, Next, Previous) above the touch wheel. The 3rd Generation iPod also introduced the iPod dock connector on the bottom of the iPod.
|
|
|
BAT-3G
| Part No. |
BAT-3G |
| Capacity: |
850 mAh |
| Replaces: |
iPod battery model
616-0159, E225846 |
Package Includes:
High-capacity iPod battery, two non-scratching nylon case opening tools, and a CD-ROM with QuickTime installation videos. |
|
 |
4th Generation iPod
4th Generation iPod features the Apple Click Wheel (with integrated Play, Menu, Next, Previous buttons) and a dock connector on the bottom of the iPod. 4th Generation iPod has a grayscale display and includes 20GB, 30GB, and 40GB* models, as well as the U2 Special Edition iPod.
Due to the physical size of the iPod, the 40GB grayscale iPod model is only compatible with Sonnet's replacement battery (BATG-4GC) for 4th Generation color iPods. The size of the iPod's hard drive is engraved on the back of the case. You can also determine the hard drive size by turning on the iPod and selecting
Main Menu > Settings > About.
|
|
|
BATG-4G
| Part No. |
BATG-4G |
| Capacity: |
750 mAh |
| Replaces: |
iPod battery model: 616-0183 |
Package Includes:
High-capacity iPod battery, two non-scratching nylon case opening tools, one specialized T-6 torx screwdriver, and a CD-ROM with QuickTime installation videos.
*Note:
The 40GB grayscale iPod is compatible with Sonnet's battery replacement for 4th Generation color iPods (Part No. BATG-4G). See below.
|
|
 |
4th Generation Color iPod
4th Generation color iPod features the Apple Click Wheel (with integrated Play, Menu, Next, Previous buttons), a dock connector on the bottom of the iPod, and a color screen. 4th Generation color iPods include all models designated as photo or color iPods.
|
|
|
BATG-4GC
| Part No. |
BAT-4GC |
| Capacity: |
900 mAh |
| Replaces: |
iPod battery model: 616-0206 |
Package Includes:
High-capacity iPod battery, two non-scratching nylon case opening tools, one specialized T-6 torx screwdriver, and a CD-ROM with QuickTime installation videos.
*Note:
This battery replacement is also compatible with the 40GB iPod with Click Wheel and grayscale display.
|
|
 |
5th Generation iPod video
(30GB model)
iPod video features a larger 2.5" color screen, Apple Click Wheel (with integrated Play, Menu, Next, Previous buttons) and a dock connector on the bottom of the iPod.
The size of the iPod's hard drive is engraved on the back of the case. You can also determine the hard drive size by turning on the iPod and selecting
Main Menu > Settings > About.
|
|
|
BATG-5G30
|
Part No.
|
BATG-5G30
|
|
Capacity:
|
520 mAh
|
|
Replaces:
|
iPod battery model: 616-0229, 616-0230
|
Package Includes:
High-capacity iPod battery, two non-scratching nylon case opening tools, and a CD-ROM with QuickTime installation videos.
|
|
|
5th Generation iPod video
(60GB & 80GB model)
iPod video features a larger 2.5" color screen, Apple Click Wheel (with integrated Play, Menu, Next, Previous buttons) and a dock connector on the bottom of the iPod.
The size of the iPod's hard drive is engraved on the back of the case. You can also determine the hard drive size by turning on the iPod and selecting
Main Menu > Settings > About.
|
|
|
BATG-5G60
| Part No. |
BATG-5G60 |
| Capacity: |
750 mAh |
| Replaces: |
iPod battery model: 616-0232 |
Package Includes:
High-capacity iPod battery, two non-scratching nylon case opening tools, and a CD-ROM with QuickTime installation videos. |
|
 |
6th Generation iPod classic
(80GB & 120GB model)
iPod classic features an aluminum enclosure, larger 2.5" color screen, Apple Click Wheel (with integrated Play, Menu, Next, Previous buttons) and a dock connector on the bottom of the iPod.
|
|
|
BATG-5G30
| Part No. |
BATG-5G30 |
| Capacity: |
520 mAh |
| Replaces: |
iPod battery model: 616-0229, 616-0230 |
Package Includes:
High-capacity iPod battery, two non-scratching nylon case opening tools, and a CD-ROM with QuickTime installation videos.
Note: Installing battery into iPod classic is similiar to iPod video installation. For iPod classic battery installation, please refer to iPod video battery installation. |
|
|
6th Generation iPod classic
(160GB model)
iPod classic features an aluminum enclosure, larger 2.5" color screen, Apple Click Wheel (with integrated Play, Menu, Next, Previous buttons) and a dock connector on the bottom of the iPod.
|
|
 |
BATG-5G60
| Part No. |
BATG-5G60 |
| Capacity: |
750 mAh |
Package Includes:
High-capacity iPod battery, two non-scratching nylon case opening tools, and a CD-ROM with QuickTime installation videos.
Note: Installing battery into iPod classic is similiar to iPod video installation. For iPod classic battery installation, please refer to iPod video battery installation. |
|
 |
iPod mini
iPod mini features a compact, anodized aluminum case, Apple Click Wheel (with integrated Play, Menu, Next, Previous buttons), and a dock connector on the bottom of the iPod.
|
|
|
BATG-MINI
| Part No. |
BAT-MINI |
| Capacity: |
600 mAh |
| Replaces: |
iPod battery model: EC003 |
Package Includes:
High-capacity iPod battery, one non-scratching nylon case opening tool, one micro flat-blade and one micro philips screwdriver, and a CD-ROM with QuickTime installation videos.
Note: Professional installation recommended.
|
|
|
|
 |
|
|
What is the warranty on Sonnet's iPod replacement batteries?
|
|
Sonnet's iPod replacement batteries come with a one-year limited warranty from the date of purchase.
|
|
|
How difficult is it to install a Sonnet iPod replacement battery?
|
|
All Sonnet iPod replacement batteries come with the necessary tools to perform the installation. Sonnet also includes a CD-ROM with short, easy-to-follow QuickTime videos (in English, French, German, Japanese, and Spanish) of how to perform the iPod battery replacement. If you follow the installation videos carefully, you should have no problems performing the task yourself; however, due to the higher level of difficulty installing a replacement battery in an iPod mini, we recommend professional installation.
If you need professional installation of your iPod replacement battery, a Sonnet authorized iPod battery service center will perform the installation for a small fee.
|
|
|
What are the different battery capacities? What does mAh mean?
|
|
Sonnet sells the highest capacity batteries on the market for your iPod. A battery's total capacity is determined by milliamp hour (mAh) rating. A longer mAh rating will generally mean longer play time for your iPod between charges.
|
|
|
Which iPod do I own?
|
|
Apple has released several generation of iPods and it can be a little confusing to determine which model you own. To easily identify your iPod, please see our iPod Compatibility Chart.
|
|
|
How do I know if my iPod needs a replacement battery?
|
|
Over time, all rechargeable batteries lose their charge and require replacement. If you've owned your iPod for more than one to two years, odds are your iPod's original battery has lost most of its original charge capacity. If you've found your iPod playtime has dramatically decreased since the time you purchased it, you are in need of a simple battery replacement from Sonnet. Find your iPod model from our iPod Compatibility Chart and click the Buy Now button. It's that simple to love your iPod even longer.
|
|
|
Do you offer batteries for iPod with video (5G) and iPod classic (6G)?
|
|
Yes. Sonnet offers replacement batteries for fifth and sixth generation iPods that offer same capacity as the original factory installed battery. To install a battery into an iPod classic, simply follow the video instructions for the iPod video provided on the CD-ROM included with the battery.
|
|
|
Do you offer batteries for iPod nano?
|
|
No. iPod nano has a soldered in battery that is not user replaceable.
|
|
|
