Storage Systems


Fusion D400QR5

Fusion D400QR5

Desktop, 4-drive, removable storage, 2-8 terabytes, quad interface: eSATA, FireWire 800, FireWire 400, USB 2.0. Integrated hardware RAID 5 controller, integrated controls and display, SATA-interface bandwidth: 225 MB/sec. Recommended to use with Tempo SATA E4P, Tempo SATA X4P, or Tempo SATA Pro ExpressCard/34 host controller cards.

Fusion R400QR5Fusion R400QR5

Rackmount, 4-drive, removable storage, 2-8 terabytes, quad interface: eSATA, FireWire 800, FireWire 400, USB 2.0. Integrated hardware RAID 5 controller, integrated controls and display, SATA-interface bandwidth: 225 MB/sec. Recommended to use with Tempo SATA E4P, Tempo SATA X4P, or Tempo SATA Pro ExpressCard/34 host controller cards.

Fusion D400Q

Fusion D400Q

Desktop, 4-drive, removable storage, 2-8 terabytes, quad interface: eSATA, FireWire 800, FireWire 400, USB 2.0. 4-drive RAID 0 stripe, SATA-interface bandwidth: 220 MB/sec. Recommended to use with Tempo SATA E4P, Tempo SATA X4P, or Tempo SATA Pro ExpressCard/34 host controller cards.

Rusion R400QFusion R400Q

Rackmount, 4-drive, removable storage, 2-8 terabytes, quad interface: eSATA, FireWire 800, FireWire 400, USB 2.0. 4-drive RAID 0 stripe, SATA-interface bandwidth: 220 MB/sec. Recommended to use with Tempo SATA E4P or Tempo SATA X4P host controller cards.

Fusion D500P

Fusion D500P

Desktop, 5-drive, removable storage, 2.5-10 terabytes, locking eSATA interface which has 5-drive port multiplier support. 5-drive, RAID 0 stripe bandwidth: 240 MB/sec. Recommended to use with Tempo SATA E4P, Tempo SATA X4P, or Tempo SATA Pro ExpressCard/34 host controller cards.

Fusion R800RAIDFusion R800RAID

Rackmount, 8-drive, removable storage, 4-16 terabytes with included PCIe RAID 0, 1, 4 (DV RAID), 5, 6, 10 controller. 8-drive, RAID 5 protected mode bandwidth: 690 MB/sec read, 677 MB/sec write.

Fusion D800RAID

Fusion D800RAID

Desktop 8-Drive SATA storage system, removable storage, 4-16 terabytes, with included PCIe RAID 0, 1, 4 (DV RAID), 5, 6, 10 controller. RAID 5 protected mode bandwidth: 690 MB/sec read, 677 MB/sec write.

Fusion RX1600FibreFusion RX1600Fibre

Rackmount, 16-drive RAID Fibre Channel storage system with 4-port 8Gb FC interface, removable storage, 16 or 32 terabytes, with internal RAID 0, 1, 4, DVRAID, 5, 6, 10, 50 controller. RAID 5 protected mode aggregate bandwidth: 1030 MB/sec read, 750 MB/sec write.

Fusion DX800RAID

Fusion DX800RAID

Desktop 8-Drive SATA storage system with Internal SAS Expander, removable storage, 4-16 terabytes, with included PCIe RAID 0, 1, 4 (DV RAID), 5, 6, 10 controller. RAID 5 protected mode bandwidth: 815 MB/sec read, 715 MB/sec write.

Fusion RX1600RAIDFusion RX1600RAID

Rackmount, 16-drive RAID SATA storage system with internal SAS expander, removable storage, 16 or 32 terabytes, with included PCIe RAID 0, 1, 4, DVRAID, 5, 6, 10 controller. RAID 5 protected mode bandwidth: 1000 MB/sec read, 750 MB/sec write.

Fusion F2

Fusion F2

Portable 2-Drive RAID SATA Storage System with eSATA ports.

Fusion Mobile Rack

Fusion Mobile Rack

Internal, 1-bay, removable storage for PC with internal SATA interface. Provided without hard drive for customer configuration. Performance, capacity, and reliability dependent on drive choice.

Fusion F3Fusion F3

Desktop, 2-drive hardware RAID storage system, 1–3 terabytes storage, quad interface: eSATA, FireWire 800, FireWire 400, USB 2.0. 2-drive RAID 0 stripe eSATA interface bandwidth: 200 MB/sec. Recommended to use with Tempo SATA E4P, Tempo SATA X4P, or Tempo SATA Pro ExpressCard/34 host controller cards.

QioQio

Desktop and portable, professional, high-speed, universal media reader/writer and eSATA host controller with included PCIe bus extender (ExpressCard/34 or PCIe) adapter card. Supports CompactFlash®, P2, SxS and many other memory cards. Supports ExpressCard/34 and CardBus adapter cards. Recommended to use with Fusion F2, Fusion D400QR5, and Fusion D500P storage systems.

Rusion R400QFusion R400P

Rackmount 4-drive SATA storage system with port multiplier; compatible with eSATA host controllers with port multiplier support. 2-8 terabytes, quad interface: eSATA, FireWire 800, FireWire 400, USB 2.0. 4-drive RAID 0 stripe, SATA-interface bandwidth: 220 MB/sec. Recommended to use with Tempo SATA E4P or Tempo SATA X4P host controller cards.




PCIe SATA Host Adapter Cards

PCIe (PCI Express) cards are for desktop computers with PCIe slots. Mac Pro and later Power Mac G5 computers, and some PCs have PCIe slots. PCIe cards can have multiple data lanes for more bandwidth to the host computer. For example, a four-lane card will be designated as PCIe x4.


Tempo SATA E4P

Tempo SATA E4P

Professional, external, 4-port SATA II, x4 PCIe card. Each port supports port multiplier functionality at 3Gb/s to interface to multiple drives. One card supports up to four Fusion D400Q, Fusion D500P, Fusion F3, or Fusion R400Q storage systems at full bandwidth.

Tempo SATA E4i

Tempo SATA E4i

Professional Internal 4-port SATA II, x4 PCIe card. Each port supports 3Gb/sec. In later Power Mac G5 models (with PCIe slots), this card is a perfect match for the Sonnet G5 Jive, a 3-bay internal storage expansion system for the Power Mac G5.

Tempo SATA E2P

Tempo SATA E2P

External, 2-port  SATA II, x1 PCIe card. Each port supports port multiplier functionality at 3Gb/s to interface to multiple drives. Not recommended for high-performance RAID configurations.




PCI/PCI-X SATA/ATA Host Adapter Cards
PCI/PCI-X cards are for desktop computers with PCI or PCI-X slots. PCI-X cards are the fastest versions (64-bit, 133 MHz) of PCI cards. PCI-X cards work in PCI slots and PCI cards will work in PCI-X slots. PCI-X cards achieve full performance in PCI-X slots. Some early Power Mac G5 and some PCs have PCI-X slots. Power Mac G4 and some early Power Mac G5 computers, and some PCs have PCI slots.


Tempo HD

Tempo HD

Internal, 2-port ATA/133 PCI card with 2.5" hard drive mounting option.

Tempo SATA X4i

Tempo SATA X4i

Professional, internal, 4-port SATA II, PCI-X card. Each port supports 3Gb/sec. In earlier Power Mac G5 models (with PCI-X slots), this card is a perfect match for the Sonnet G5 Jive, a 3-bay internal storage expansion system for the Power Mac G5.

Tempo SATA X4P
Tempo SATA X4P

Tempo SATA X4P

Professional, external, 4-port SATA II, PCI-X card. Each port supports port multiplier functionality at 3Gb/s to interface to multiple drives. One card supports up to four Fusion D400Q, Fusion D500P, Fusion F3, or Fusion R400P storage systems at full bandwidth.

Tempo SATA

Tempo SATA

Internal, 2-port SATA, PCI card. 1.5Gb/s. Bootable. Macintosh only.




ExpressCard/34 SATA/ATA Host Adapter Cards
ExpressCards are for notebook computers. MacBook Pro and some PC notebooks have ExpressCard slots. ExpressCard/34 is a narrow version (34mm) of ExpressCard (54mm). ExpressCard/34 cards will fit in either ExpressCard/34 or ExpressCard slots.


Tempo SATA edge ExpressCard/34

Tempo SATA edge ExpressCard/34

External, compact, 1-port SATA II, ExpressCard/34. Supports port multiplier functionality at 3Gb/s to interface to multiple drives. Supports up to one Fusion D400QR5 or Fusion D500P storage system. Bandwidth may be limited by notebook architecture.

Tempo SATA Pro ExpressCard/34

Professional, External, 2-port SATA II, ExpressCard/34. Each port supports port multiplier functionality at 3Gb/s to interface to multiple drives. Supports one Fusion F2, or up to two Fusion D400Q, Fusion D500P, or Fusion F3 storage systems. Supports sustained data transfers to 200 MB/sec.

Tempo SATA ExpressCard 34

External, 2-port SATA II, ExpressCard/34. Each port supports port multiplier functionality at 3Gb/s to interface to multiple drives. One card supports up to two Fusion D400Q or Fusion D500P storage systems. Bandwidth may be limited by notebook architecture.




Cables/Spares


External SATA Cables

SATA Cables, External

External SATA cables, 1 meter and 2 meter, rated to 3Gb/sec.

Fusion RAID Drive Modules (Silver ABS)

Fusion RAID Drive Modules (Silver ABS)

Spare drive modules for Fusion DX800RAID, RX1600Fibre, RX1600RAID, and RX1600 Expansion storage systems

Internal SATA Cables

SATA Cables, Internal

Tempo Serial ATA Cable Kit includes 0.5m internal SATA cable (rated to 3GB/sec), and Power “Y” cable.

Fusion RAID Drive Modules

Fusion RAID Drive Modules (Gray ABS)

Spare drive modules for Fusion DX800RAID storage systems

eSATA Extender Cable

eSATA Extender Cable

2-Port SATA-To-eSATA adapter; compatible in Mac Pro Computers.

Fusion Spare Tray (Black)

Fusion Spare Tray (Black)

Spare drive tray is compatible with Fusion D400, D500, D800, R400, and R800 storage systems

Internal ATA Cables

ATA Cables, Internal

Custom ATA cables for connecting up to four additional ATA drives in Power Mac G4 computers. Tempo Trio PCI card required.

Fusion Spare Tray (Silver)

Fusion Spare Tray (Silver)

Spare drive tray is compatible with Fusion D400, D500, D800, R400, and R800 storage systems

Fusion Quiet Fan

Fusion Quiet Fan

Spare fan module for Fusion desktop storage systems except Fusion DX800RAID and Fusion F3.

Fusion Spare Tray (Silver)

Fusion Spare Tray (Silver)

Spare drive tray is compatible with Fusion DX800RAID, RX1600Fibre, RX1600RAID, and RX1600 Expansion storage systems

Fusion Rack Slide Set

Fusion Rack Slide Set

Fusion rack slide set for17.5-21", 23-26.5", 27-30.5", and 29-32.5" rack.

Fusion Spare Tray (Gray)

Fusion Spare Tray (Gray)

Spare drive tray is compatible with Fusion DX800RAID storage systems

Fusion RAID Drive Modules (Silver Metal)

Fusion RAID Drive Modules (Silver Metal)

Spare drive modules for Fusion D400, D500, D800, R400, and R800 storage systems

Fusion World Travel Power Adapter

Fusion World Travel Power Adapter

AC power adapter for Fusion F2, FireWire 800 Pro ExpressCard/34, FireWire/USB ExpressCard/34.
