Technical Specifications

Mac, Windows & Linux Logos

DuoModo Enclosures

    DuoModo Dual-Module Desktop Enclosure

    Hardware

    Part Number

    • DM-ENC-2M-D

    Warranty

    • 2-year

    Form Factor

    • Desktop enclosure

    Dimensions (WxDxH)

    • 6.9 x 16.7 x 9.1 in (17.4. x 42.2 x 23.2 cm)

    Weight

    • 3.85 lbs (1.75 kg)

    Compliance

    • RoHS 3 (Directive 2015/863)
    • IEC62368-1 and IEC62368-2

    Package Contents

    • DuoModo Dual-Module Desktop Enclosure

    Support Links

    Support Knowledge Base

    Drivers, Documentation, FAQs

    Product Manual

    PDF Icon

    DuoModo Single-Module Desktop Enclosure

    Hardware

    Part Number

    • DM-ENC-1M-D

    Warranty

    • 2-year

    Form Factor

    • Desktop enclosure

    Dimensions (WxDxH)

    • 3.5 x 16.6 x 9.1 in (8.9 x 42.2 x 23.1 cm)

    Weight

    • 2.7 lbs (1.22 kg)

    Compliance

    • RoHS 3 (Directive 2015/863)
    • IEC62368-1 and IEC62368-2

    Package Contents

    • DuoModo Single-Module Desktop Enclosure

    Support Links

    Support Knowledge Base

    Drivers, Documentation, FAQs

    Product Manual

    PDF Icon

    DuoModo Dual-Rackmount Rackmount Enclosure

    Hardware

    Part Number

    • DM-ENC-2M-R

    Warranty

    • 2-year

    Form Factor

    • 2U rackmount enclosure

    Dimensions (WxDxH)

    • 19 x 16.5 x 3.5 in (48.3x 41.9 x 8.9 cm)

    Weight

    • 14.05 lbs (6.37 kg)

    Compliance

    • RoHS 3 (Directive 2015/863)
    • IEC62368-1 and IEC62368-2

    Package Contents

    • DuoModo Dual-Module Rackmount Enclosure
    • Extension rails for rack depth 16-24 inches
    • Cover plate (for use in single-module applications)

    Support Links

    Support Knowledge Base

    Drivers, Documentation, FAQs

    Product Manual

    PDF Icon

    DuoModo Modules

      xMac mini Module

      Compatibility

      Mac Compatibility

      Hardware

      Part Number

      • DM-MOD-ZM

      Warranty

      • 2-year

      Form Factor

      • Expansion system module

      Front Panel Connectors

      • One Thunderbolt (USB Type-C) port
      • Two USB 3.2 (10Gbps) Type-C ports
      • One USB 3.2 (10Gbps) Type A port

      Internal Connectors

      • One Thunderbolt (USB Type-C) port to Mac mini
      • One USB 3.2 (10Gbps) Type A port for thumb drive or dongle
      • Two M-keyed (NVMe) M.2 sockets (each connected at PCIe x2)

      SSDs(1)

      • One or two M.2 2280 NVMe PCIe SSDs (with or without heat sink)
      • Supported SSDs Compatibility Chart
      PDF Icon

      Power Supply

      • Universal 96W, 100-240V AC, 50-60Hz
      • C14-type power connector

      Operating Temperature

      • 0ºC to 35ºC (32ºF to 95ºF)

      Dimensions (WxDxH)

      • 3.3 x 16.4 x 8.5 in. (8.4 x 41.6 x 21.7 cm)

      Weight

      • 4.95 lbs (2.25 kg)

      Compliance

      • RoHS 3 (Directive 2015/863)
      • IEC62368-1 and IEC62368-2

      Package Contents

      • xMac mini Module
      • Power cord
      • 0.5-meter Thunderbolt 3 (40Gbps) cable
      • Documentation

      Support Links

      Support Knowledge Base

      Drivers, Documentation, FAQs

      Product Manual

      PDF Icon

      Technical Notes

      • macOS 10.14.6+ supports both 512 and 4k block size SSDs, but macOS 10.13.6 supports only 4k block size SSDs. SSDs 1TB or larger are shipped from the factory programmed with a 4k block size. If you have smaller SSDs that are programmed with 512 block size, and you need to be compatible with macOS 10.13.6, you may need to reprogram your SSDs to a 4k block size. See this tech note for more details.

      eGPU Module

      Compatibility

      Mac Compatibility

      • Intel Mac with Thunderbolt 3 ports
      • macOS 10.13.6+
      • AMD Radeon RX 570, 580, Vega 56, Vega 64
      • AMD Radeon Pro WX 7100, 8200, 9100
      • macOS 10.14.6+(1)
      • Support added for AMD Radeon RX 560 and 590
      • Support added for two eGPUs
      • Support added for Parallels Desktop for Mac(2)
      • macOS 10.15.7+
      • Support added for AMD Radeon RX 5500, 5500 XT, 5600, 5700, 5700 XT
      • Support added for AMD Radeon Pro W5500, W5700
      • macOS 11.5
      • Support added for AMD Radeon RX 6800, 6800 XT, 6900 XT
      • Support added for AMD Radeon Pro W6800
      • M1 Macs do not support eGPUs
      • Thunderbolt 2 or Thunderbolt 1 Macs do not support eGPUs
      • Windows 10 under Bootcamp on any Mac does not support eGPUs

      Windows Compatibility

      • Windows PC with a Thunderbolt 3 or Thunderbolt 4 port
      • Windows 10 (64-bit Edition, Version 2004 or greater)

      Monitor Compatibility

      • 1080p, 4K, and 5K monitors using DP or HDMI ports
      • 4K, 5K, and 6K Thunderbolt 3 monitors require a GPU card with USB-C output(3)
      • 49” 5120x1440 Dual QHD monitors using a DP port:
      • Dell Ultrasharp 49 Curved Monitor U4919DW
      • LG 49 inch 32:9 UltraWide Dual QHD IPS Curved LED Monitor 49WL95C-W
      • Philips Brilliance 32:9 Superwide Curved LCD Display 499P9H/27
      • Samsung 49” CRG9 Dual QHD Curved QLED Gaming Monitor LC49RG90SSNXZA
        • 8K displays are compatible with Windows(4), but not compatible with macOS

        Hardware

        Part Number

        • DM-MOD-GPU

        Warranty

        • 2-year

        Form Factor

        • eGPU Module

        External Connectors

        • One Thunderbolt 3
        • Power (C14-type)

            Internal Connectors

            • Two 8-pin (6+2 pin) power connectors

            Expansion Slot

            • One x16 mechanical (x4 electrical, Thunderbolt 3 spec) PCIe 3.0

            GPU Card Supported

            • One full-length, full-height, 2.5-slot GPU card
            • Maximum GPU card size is 312 mm x 140mm x 58mm

            Power Supply

            • Universal 800W, 100-240V AC, 50-60 Hz
            • Supports cards requiring up to 750W of peak power

            Eco-Friendly Power Management

            • See video for description

            Standy Power

            • Consumes 8.5W (sleep) / 14W (idle)

            Operating Temperatures

            • 0˚C to 35˚C (32˚F to 95˚F)

            Dimensions (WxDxH)

            • 3.3 x 16.6 x 8.5 in. (8.4 x 42.2 x 21.6cm)

            Weight

            • 5.8 lbs (2.63 kg)

            Compliance

            • RoHS 3 (Directive 2015/863)
            • IEC62368-1 and IEC62368-2

            Package Contents

            • DuoModo eGPU Module
            • Power cord
            • 0.7-meter Thunderbolt 3 (40Gbps) cable
            • ThunderLok 3 Thunderbolt Connector Retainer Clip(5)
            • Card support bracket (secures AMD Radeon Pro or NVIDIA Quadro for transport)
            • Card support bracket screws
            • Documentation

            Graphics Card Compatibility Chart

            List of AMD and NVIDIA GPU cards arranged by card manufacturer, compatibility determined by the card’s power requirements, and eGPU Module's power capabilities. Maximum GPU card size 312mm x 140mm x 58mm.

            PDF Icon

            Support Links

            Support Knowledge Base

            Drivers, Documentation, FAQs

            Product Manual

            Step-by-step card installation instructions

            PDF Icon

            External Graphics Setup and Usage Guide (macOS)

            PDF Icon

            External Graphics Setup and Usage Guide (Windows 10)

            PDF Icon

            Technical Notes

            • Under macOS 10.14.6, a Mac mini is compatible with a DuoModo eGPU Module with Vega 56, Vega 64, WX 8200, and WX 9100. A Mac mini with a DuoModo eGPU Module with an RX 560/570/580/590 must be booted with a monitor connected to the Mac mini’s HDMI port. The monitor may be moved to the GPU after booting. This anomaly is fixed in macOS 10.15.7+.
            • See Using eGPU with Parallels Desktop for Mac.
            • For example, the AMD Radeon Pro W5700 has a USB-C Alt-Mode DisplayPort output.
            • 8K displays require a GPU card that supports 8K displays.
            • ThunderLok 3 compatible specifically with Sonnet 0.5- and 0.7-meter Thunderbolt 3 cables; Sonnet 1- and 2-meter Thunderbolt 3 cables require ThunderLok 3L.

            Accessories

            Thunderbolt 3 Cable (0.7-meter)

            Thunderbolt 3 Cable (0.7-meter)

            Part No. TCB-TB3-07M

            • 0.7-meter Thunderbolt 3 (40Gbps) cable
            • Delivers full 40Gb/s bandwidth
            • Supports 100W of Power Delivery (PD)
            • Compatible with Sonnet ThunderLok 3
            Buy Now
            ThunderLok 3L

            ThunderLok 3L

            Part No. TB3-LOK2L

            Secures Sonnet 1- and 2-meter Thunderbolt 3 (40Gbps) active cables with ThunderLok 3L-compatible products.

            Not compatible with Sonnet 0.5- or 0.7-meter Thunderbolt 3 (40Gbps) passive cables.
            Buy Now
            ThunderLok 3

            ThunderLok 3

            Part No. TB3-LOK2

            Secures Sonnet 0.5- or 0.7-meter Thunderbolt 3 (40Gbps) passive cables with ThunderLok 3-compatible products.

            Not compatible with Sonnet 1- or 2-meter Thunderbolt 3 (40Gbps) active cables.
            Buy Now

            Echo III Module

            Compatibility

            Mac Compatibility

            Windows Compatibility

            • PC with Thunderbolt 3 or Thunderbolt 4 ports
            • Windows 10 (64-bit Edition Version 2004 or greater, see note)
            • Important Note: Windows computers require the latest BIOS and Thunderbolt drivers to support this product. Check with your computer manufacturer for update information.

            Linux Compatibility

            • Linux® computer with Thunderbolt 3 or Thunderbolt 4 ports
            • Linux Kernel 5.0+

            PCIe Card Compatibility

            For a list of compatible PCIe cards, view the PDF of Sonnet's PCIe Card Thunderbolt Compatibility Chart

            PDF Icon

            Hardware

            Part Number

            • DM-MOD-E3

            Warranty

            • 2-year

            Form Factor

            • Expansion system module

            External Connectors

            • Two Thunderbolt 3 ports
            • Power (C14-type)

            Internal Connector

            • 6-pin Mini-Fit Jr (same type as on legacy Mac Pro motherboard; provides up to 75W of power for PCIe cards that require supplemental power)

            Expansion Slots (Facing Rear, Left to Right)(1)

            • One x8 mechanical (x8 electrical) PCIe 3.0
            • One x16 mechanical (x8 electrical) PCIe 3.0
            • One x8 mechanical (x4 electrical) PCIe 3.0

            PCIe Cards Supported

            • One full-length, full-height, double-width PCIe card, plus one single-width card or
            • Three full-length, full-height, single-width PCIe cards

            Power Supply

            • Universal 400W, 115-230V AC, 50-60 Hz(8)

            Operating Temperature

            • 0ºC to 35ºC (32ºF to 95ºF)

            Dimensions (WxDxH)

            • 3.3 x 16.6 x 8.5 in. (8.4 x 42.2 x 21.7 cm)

            Weight

            • 4.95 lbs (2.25 kg)

            Compliance

            • RoHS 3 (Directive 2015/863)
            • IEC62368-1 and IEC62368-2

            Package Contents

            • Echo III Module
            • Power cord
            • 0.7-meter Thunderbolt 3 (40Gbps) cable
            • ThunderLok 3 Thunderbolt Connector Retainer Clip(2)
            • Mounting screws
            • Documentation

            Support Links

            Support Knowledge Base

            Drivers, Documentation, FAQs

            Product Manual

            PDF Icon

            Technical Notes

            • When set to HDX compatibility mode, PCIe slots operate in PCIe 2.0 mode and the chassis’ bandwidth is limited to 1750 MB/s.
            • ThunderLok 3 compatible specifically with Sonnet 0.5- and 0.7-meter Thunderbolt 3 cables; Sonnet 1- and 2-meter Thunderbolt 3 cables require ThunderLok 3L.
            • While the Echo III features a 40Gbps Thunderbolt 3 interface, some computers equipped with Thunderbolt 3 use an x2 PCIe lane implementation of Thunderbolt 3 technology that limits PCIe performance to 20Gbps.
            • Full performance requires the use of the included or comparable Thunderbolt 3 (40Gbps) cables; look for the Thunderbolt icon AND the number 3 on the connector housings to identify these cables. Full performance supported by any Thunderbolt 4 cable.
            • Second Thunderbolt 3 port supports Thunderbolt 2 and Thunderbolt peripheral devices on Macs when used with the Apple Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter, sold separately.
            • Second Thunderbolt 3 port supports USB 3.2 Gen 1 (5Gb) or Gen 2 (10Gb) devices when connected with proper cable or adapter (sold separately).
            • Assuming that a 40Gbps Thunderbolt 3 connection is established, all Thunderbolt 3 computers support one 4K monitor directly attached to the pass-through Thunderbolt 3 port, without affecting PCIe bandwidth to the device. Using two 4K monitors or a single 5K monitor attached to the pass-through Thunderbolt 3 port reduces available PCIe bandwidth to the device. Two 4K monitors requires either: 1) for Thunderbolt 3 Macs or for Windows Thunderbolt 3 PCs that support two monitors—a Thunderbolt 3 to Dual DisplayPort adapter; or 2) for Windows Thunderbolt 3 PCs that support two monitors—a 4K monitor with multi-stream transport support (DP out).
            • Power supply will operate as low as 90VAC, with linear power derating from 400W @ 115VAC to 320W @ 90VAC.

            Accessories

            Thunderbolt 3 Cable (0.7-meter)

            Thunderbolt 3 Cable (0.7-meter)

            Part No. TCB-TB3-07M

            • 0.7-meter Thunderbolt 3 (40Gbps) cable
            • Delivers full 40Gb/s bandwidth
            • Supports 100W of Power Delivery (PD)
            • Compatible with Sonnet ThunderLok 3
            Buy Now
            ThunderLok 3L

            ThunderLok 3L

            Part No. TB3-LOK2L

            Secures Sonnet 1- and 2-meter Thunderbolt 3 (40Gbps) active cables with ThunderLok 3L-compatible products.

            Not compatible with Sonnet 0.5- or 0.7-meter Thunderbolt 3 (40Gbps) passive cables.
            Buy Now
            ThunderLok 3

            ThunderLok 3

            Part No. TB3-LOK2

            Secures Sonnet 0.5- or 0.7-meter Thunderbolt 3 (40Gbps) passive cables with ThunderLok 3-compatible products.

            Not compatible with Sonnet 1- or 2-meter Thunderbolt 3 (40Gbps) active cables.
            Buy Now
            Power Cable (OWC Accelsior PCIe Card)

            Power Cable (OWC Mercury Accelsior Pro Q)

            Part No. TCB-EXCEL

            Power cable to connect OWC Mercury Accelsior Pro Q in Echo, Echo Express, xMac mini Server and xMac Pro Server expansion systems with auxiliary power connectors.

            Buy Now

            DuoModo Pre-configured Systems

              DuoModo xMac mini/Echo III Desktop

              Hardware

              Part Number

              • DM-ZM-E3-D

              Warranty

              • 2-year

              Form Factor

              • Desktop expansion system

              Dimensions (WxDxH)

              • 6.9 x 16.7 x 9.1 in (17.4 x 42.2 x 23.2 cm)

              Weight

              • 13.75 lbs (6.24 kg)

              Compliance

              • RoHS 3 (Directive 2015/863)
              • IEC62368-1 and IEC62368-2

              Package Contents

              • Dual-Module Desktop Enclosure
              • xMac mini Module
              • Echo III Module
              • Power cord x2
              • 0.5-meter Thunderbolt 3 (40Gbps) cable
              • 0.7-meter Thunderbolt 3 (40Gbps) cable
              • ThunderLok 3 Thunderbolt Connector Retainer Clip
              • Documentation

              DuoModo xMac mini/Echo III Rackmount

              Hardware

              Part Number

              • DM-ZM-E3-R

              Warranty

              • 2-year

              Form Factor

              • 2U rackmount expansion system

              Dimensions (WxDxH)

              • 19 x 16.5 x 3.5 in (48.3 x 41.9 x 8.9 cm)

              Weight

              • 24 lbs (10.9 kg)

              Compliance

              • RoHS 3 (Directive 2015/863)
              • IEC62368-1 and IEC62368-2

              Package Contents

              • Dual-Module Rackmount Enclosure
              • xMac mini Module
              • Echo III Module
              • Power cord x2
              • 0.5-meter Thunderbolt 3 (40Gbps) cable
              • 0.7-meter Thunderbolt 3 (40Gbps) cable
              • ThunderLok 3 Thunderbolt Connector Retainer Clip
              • Extension rails for rack depth 16-24 inches
              • Documentation

              DuoModo xMac mini/eGPU Desktop

              Hardware

              Part Number

              • DM-ZM-GPU-D

              Warranty

              • 2-year

              Form Factor

              • Desktop expansion system

              Dimensions (WxDxH)

              • 6.9 x 16.7 x 9.1 in (17.4 x 42.2 x 23.2 cm)

              Weight

              • 14.6 lbs (6.62 kg)

              Compliance

              • RoHS 3 (Directive 2015/863)
              • IEC62368-1 and IEC62368-2

              Package Contents

              • Dual-Module Desktop Enclosure
              • xMac mini Module
              • eGPU Module
              • Power cord x2
              • 0.5-meter Thunderbolt 3 (40Gbps) cable
              • 0.7-meter Thunderbolt 3 (40Gbps) cable
              • ThunderLok 3 Thunderbolt Connector Retainer Clip
              • Documentation

              DuoModo xMac mini/eGPU Rackmount

              Hardware

              Part Number

              • DM-ZM-GPU-R

              Warranty

              • 2-year

              Form Factor

              • Rackmount expansion system

              Dimensions (WxDxH)

              • 19 x 16.5 x 3.5 in (48.3 x 41.9 x 8.9 cm)

              Weight

              • 24.8 lbs (11.25 kg)

              Compliance

              • RoHS 3 (Directive 2015/863)
              • IEC62368-1 and IEC62368-2

              Package Contents

              • Dual-Module Rackmount Enclosure
              • xMac mini Module
              • eGPU Module
              • Power cord x2
              • 0.5-meter Thunderbolt 3 (40Gbps) cable
              • 0.7-meter Thunderbolt 3 (40Gbps) cable
              • ThunderLok 3 Thunderbolt Connector Retainer Clip
              • Extension rails for rack depth 16-24 inches
              • Documentation

              Echo III Desktop

              Hardware

              Part Number

              • ECHO-3D-TB3

              Learn More ›

              Echo III Rackmount

              Hardware

              Part Number

              • ECHO-3R-TB3

              Learn More ›

              DuoModo

              Buy Now
              Stay Connected. Sign Up for News and Deals.
              Pre-sales Questions?
              Call us at 1-949-472-2772 or email

              Company

              Products Videos Store Where to Buy Support What's New Company Info

              Support

              Contact Knowledge Base Warranty Info

              Legal

              Privacy Policy Terms of Use Legal & Trademarks Site Map

              Language

              English (USA) Japanese (日本語)
              Copyright © Sonnet Technologies, Inc. All rights reserved.
