Compatibility

Computer System Requirements

To support maximum performance when using two bandwidth-hungry PCIe cards, Echo II DV T5 Desktop requires the following:

• Two connections between the Echo II DV T5 module and the host computer(s) with two Thunderbolt 5 ports with independent PCIe bandwidth.

• For example:

• Mac (M4/M5 Pro, M4/M5 Max, M3/M5 Ultra series)
• Some pro Windows laptops with two Thunderbolt 5 ports
• Connecting each card to a different Thunderbolt 5 computer

Mac Compatibility

• Mac with Thunderbolt 5, Thunderbolt 4, Thunderbolt/USB4, or Thunderbolt 3 ports
• macOS 15+; compatible with macOS 27

Windows Compatibility

• Windows computer with Thunderbolt 5, Thunderbolt 4, or USB4 ports
• Windows 11 25H2+

Linux Compatibility

• Linux computer with Thunderbolt 5, Thunderbolt 4, or USB4 ports
• Supported Linux kernel, 6.6 or later

PCIe Card Compatibility

For a list of compatible PCIe cards, see the following PDF

Hardware

Part Number

• ECHO-2DDV-T5

Warranty

• 2-year

Form Factor

• 2U Thunderbolt desktop enclosure

External Connectors

• Four Thunderbolt ports
• Power (C14-type)

Thunderbolt 5 Computer Ports

• Cables Supported

• Thunderbolt 5 or Thunderbolt 4 cables

• Cables Not Supported

• Thunderbolt optical cables

Thunderbolt 5 Peripheral Ports

Note that the downstream ports are not necessarily Thunderbolt 5 ports; they are the same as the host ports (Thunderbolt 5, Thunderbolt 4, or USB4).

• Connectivity

• With USB-C connector

• Peripherals Supported

• Thunderbolt 5, 4, 3 devices
• USB4, 3, 2, 1 devices
• Thunderbolt 5, 4, 3, and USB-C monitors
• DisplayPort and HDMI monitors (Thunderbolt compatible adapter required, sold separately)

Internal Connectors

• Two 6-pin auxiliary power; provide up to 75W of power each for PCIe cards that require supplemental power

Expansion Slots

• Two x16 mechanical (x4 electrical) PCIe 4.0

PCIe Cards Supported

• Two full-length, full-height, single-width PCIe cards

Power Supply

• Universal 400W, 115-230V AC, 50-60 Hz

Operating Temperature

• 0ºC to 35ºC (32ºF to 95ºF)

Dimensions (WxDxH)

• 3.5 x 16.7 x 9 in. (8.9 x 42.4 x 22.9 cm)

Weight

• 9.7 lbs (4.40 kg)

Package Contents

• Echo II DV T5 Desktop System
• Region-specific power cable
• Two 6-pin PCIe auxiliary power cables (installed)
• Two 0.8-meter Thunderbolt 5 cables
• Three ThunderLok-A connector locks (for securing Thunderbolt cables)
• Documentation
