Technical Specifications

Mac, Windows, and iPadOS Logos

Compatibility

Mac Compatibility

  • Mac (M1 or M2) supports only one display
  • Mac (M1/M2 Pro, M1/M2 Max, or M1 Ultra) supports two displays
  • Mac (Intel) with Thunderbolt 3 ports supports two displays
  • macOS 13 (Venutra), 12 (Monterey), or 11 (Big Sur) required
  • See Displays Compatibility PDF for Mac display support

iPad Pro Compatibility

  • M1/M2 series iPad Pro supports only one mirrored display

Windows Compatibility

  • Windows computer with Thunderbolt 4 ports supports two displays
  • Windows computer with USB4 port(4)
  • Windows computer with Thunderbolt 3 port and an Intel 8th Gen (2018) or newer CPU

Displays Compatibility

For computers and displays compatibility information, see the following PDF

Displays Compatibility PDF Download Link

HDR Compatibility

Hardware

Part Number

  • ECHO-HB5-T4

Warranty

  • 2-year

Form Factor

  • Thunderbolt hub

External Connectors

  • Four Thunderbolt 4 ports
  • One USB 3.2 Gen 2 (10Gbps) Type A charging port
  • One power connector

Thunderbolt 4 Computer Port

  • Power Delivery
  • Provides laptop charging up to 85W(1)
  • Cables Supported
  • Any Thunderbolt 4 cable (0.7-meter cable included)
  • 100W ≤ 0.8-meter 40Gbps Thunderbolt cables
  • Cables Not Supported
  • 60W 40Gbps Thunderbolt cables
  • ≥ 1.0-meter 40Gbps Thunderbolt cables

Thunderbolt 4 Peripherals Ports

  • Connectivity
  • With USB-C connector
  • Peripherals Supported
  • Thunderbolt 4
  • Thunderbolt 3
  • Thunderbolt 2 (macOS[2])
  • USB4
  • USB 3, 2.0, and 1.1 devices
  • Thunderbolt 3 and USB-C monitors
  • DisplayPort and HDMI monitors(3)
  • Charging
  • 15W capacity to charge iPad, iPhone, or other device supporting PD charging
  • Supports simultaneous charging and syncing

USB 3.2 Gen 2 Type A Port

  • Connectivity
  • With USB Type A connector
  • Peripherals Supported
  • USB 3, 2.0 and 1.1 devices
  • Data Transfer Rate
  • USB 3.2 Gen 2 (previously USB 3.1 Gen 2): 10Gbps
  • Charging
  • 7.5W capacity to charge iPad, iPhone, or other device
  • USB Battery Charging 1.2–compliant
  • Supports simultaneous charging and syncing

Power Adapter

  • Universal 100W, 100-240V AC, 50-60 Hz

Power Delivery

  • Provides laptop charging up to 85W(1)

Operating Temperatures

  • 0˚C to 35˚C (32˚F to 95˚F)

Dimensions (WxDxH)

  • Hub: 5.1 x 2.8 x 0.9 in. (12.9 x 7.2 x 2.16 cm)
  • Power Supply: 2.2 x 5.8 x 1.3 in. (5.6 x 14.8 x 3.2 cm)

Weight

  • Hub and Power Supply: 1.35 lbs (0.61 kg)
  • Complete Package: 2.30 lbs (1.04 kg)

Compliance

  • RoHS 3 (Directive 2015/863)
  • IEC62368-1 and IEC62368-2 Safety
  • FCC Part 15, Subpart B
  • CISPR 32 / EN 55032
  • UKCA
  • Power Supply (PSE certified; UL certified; VCCI certified)

Package Contents

  • Echo 5 Thunderbolt 4 Hub
  • Power adapter
  • Power cord
  • 0.7-meter Thunderbolt 4 cable
  • Documentation
Echo 5 Thunderbolt 4 Package Contents

Support Links

Support Knowledge Base

Documentation and FAQs

Product Manual

Echo 5 Thunderbolt 4 Hub Manual PDF Download Link

Technical Notes

  • Charging rate may vary because Sonnet Hub Smart Power Controller directs power to where it is needed the most. When sleeping, any connected computer that supports Thunderbolt charging will be charged to 100% by the hub.
  • Thunderbolt 2 and Thunderbolt 1 devices are supported by macOS when used with the Apple Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter (sold separately).
  • Thunderbolt compatible adapter required (sold separately).
  • When connected to a USB4 Windows host, the downstream TB4 ports become USB4 ports with the same functionality as the host computer USB4 port — which may support one display or two; which may connect at 20Gbps or 40Gbps; and/or which may or may not support PCIe tunneling.
